自编译 Transmission-daemon 的 Docker 镜像

为了熟悉 Docker，就想着把 NAS 中的对外服务全部部署在 Docker 上，一是方便以后在其它地方部署，二是在 Docker 中运行服务要比本机相对安全一些。

背景

为了以后方便部署，这里我们使用 Dockerfile 文件来在本地直接生成 Docker 镜像。

在开源界，流行这么一条安装的软件越少就越安全的理论，虽说不完全正确，但在大部分环境中它还是成立的。
依据上面的理论，我们就不选择体积较大的 Debian/Ubuntu 镜像（80+MB）了，转而使用体积小巧的 alpine 镜像（4MB）。

本文所需的文件已发布在Github-haven200。

使用hub-docker的镜像服务器

国内用户，为了提高 Docker 基础镜像的拉取速度，这里我们使用 Azure 的镜像服务。

:~$ cat > /etc/docker/daemon.json <<EOF
{
  "registry-mirrors": ["https://dockerhub.azk8s.cn"]
}
EOF && systemctl restart docker

Dockerfile

FROM alpine:latest

MAINTAINER haven200 <haven200@gmail.com>

WORKDIR /opt/src

RUN sed -i 's/dl-cdn.alpinelinux.org/mirrors.tuna.tsinghua.edu.cn/'  /etc/apk/repositories \
    && apk update && apk add --no-cache transmission-daemon \
    && mkdir -p /etc/transmission-daemon && mkdir -p /mnt/bt/kodi

COPY run.sh /opt/src/run.sh

EXPOSE 12345/tcp 12345/udp 80/tcp

VOLUME [ "/mnt/bt/kodi" ]

CMD [ "/bin/sh","/opt/src/run.sh" ]
HEALTHCHECK CMD netstat -ln | grep 12345 || exit 1

• FROM：以哪个镜像为基础。
• MAINTAINER：此镜像的维护者。
• WORKDIR：镜像的当前默认路径。
• RUN：构建 Docker 的make指令。
• COPY：将本地的文件复制到镜像的指定位置
• EXPOSE：镜像中对外提供服务的端口。
• VOLUME：需要保存文件的目录。
• CMD：最终运行指令。
• HEALTHCHECK：检查Docker镜像是否正常运行，如果出现错误则停止运行。

run.sh

Transmssion-Deamon 的配置选项全在此文件里，编译前可以自行修改。

#!/bin/bash

set -e

CONFIG_DIR=/etc/transmission-daemon
SETTINGS=$CONFIG_DIR/settings.json
TRANSMISSION=/usr/bin/transmission-daemon

GATEWAY_IP="$(ip route | grep default | awk '{print $3}')"

if [ -z $USERNAME ]; then
    USERNAME="Transmission"
fi
if [ -z $PASSWORD ]; then
    PASSWORD="password"
fi
if [ -z $RPC_PORT ]; then
    RPC_PORT=80
fi

cat > $SETTINGS <<EOF
{
    "bind-address-ipv4": "0.0.0.0",
    "bind-address-ipv6": "::",
    "download-dir": "/mnt/bt/kodi",
    "download-limit": 100,
    "download-limit-enabled": 0,
    "incomplete-dir": "/mnt/bt/kodi/.unfinished",
    "incomplete-dir-enabled": true,
    "preallocation": 2,
    "prefetch-enabled": true,
    "start-added-torrents": false,
    "umask": 91,
    "watch-dir": "/mnt/bt/kodi/torrents/",
    "watch-dir-enabled": true,
    "trash-original-torrent-files": false,
    "cache-size-mb": 128,
    "dht-enabled": true,
    "lpd-enabled": false,
    "message-level": 2,
    "encryption": 1,
    "script-torrent-done-enabled": false,
    "script-torrent-done-filename": "",
    "utp-enabled": true,
    "idle-seeding-limit": 30,
    "idle-seeding-limit-enabled": true,
    "max-peers-global": 200,
    "message-level": 1,
    "peer-congestion-algorithm": "",
    "peer-id-ttl-hours": 6,
    "peer-limit-global": 200,
    "peer-limit-per-torrent": 60,
    "peer-port": 12345,
    "peer-port-random-on-start": false,
    "peer-port-random-high": 65535,
    "peer-port-random-low": 49152,
    "peer-socket-tos": "default",
    "pex-enabled": true,
    "download-queue-enabled": true,
    "download-queue-size": 3,
    "queue-stalled-enabled": true,
    "queue-stalled-minutes": 30,
    "port-forwarding-enabled": true,
    "ratio-limit": 1,
    "ratio-limit-enabled": true,
    "rename-partial-files": true,
    "rpc-authentication-required": true,
    "rpc-enabled": true,
    "rpc-port": $RPC_PORT,
    "rpc-bind-address": "0.0.0.0",
    "rpc-host-whitelist": "",
    "rpc-host-whitelist-enabled": true,
    "rpc-url": "/transmission/",
    "rpc-username": "$USERNAME",
    "rpc-password": "$PASSWORD",
    "rpc-whitelist": "127.0.0.1,$GATEWAY_IP",
    "rpc-whitelist-enabled": true,
    "scrape-paused-torrents-enabled": true,
    "script-torrent-done-enabled": false,
    "script-torrent-done-filename": "",
    "seed-queue-enabled": false,
    "seed-queue-size": 10,
    "speed-limit-down": 2048,
    "speed-limit-down-enabled": true,
    "speed-limit-up": 500,
    "speed-limit-up-enabled": true,
    "upload-limit": 100,
    "upload-limit-enabled": 0,
    "upload-slots-per-torrent": 14,
    "alt-speed-down": 10240,
    "alt-speed-enabled": false,
    "alt-speed-time-begin": 0,
    "alt-speed-time-day": 127,
    "alt-speed-time-enabled": true,
    "alt-speed-time-end": 360,
    "alt-speed-up": 2048,
    "blocklist-enabled": false,
    "blocklist-url": "http://www.example.com/blocklist"
}
EOF

exec $TRANSMISSION -f --config-dir $CONFIG_DIR

编译 Docker 镜像

在 Dockerfile 的目录运行下面的命令

docker build -t haven200/transmission-daemon .

运行镜像

docker run -d --name transmission-daemon \
       -p 12345:12345/tcp \
       -p 12345:12345/udp \
       -p 80:80 \
       -v /mnt/bt:/mnt/bt/kodi \
       haven200/transmission-daemon

配置 Web 管理页面用户名及密码

docker run -d --name transmission-daemon \
       -p 12345:12345/tcp \
       -p 12345:12345/udp \
       -p 80:8080 \
       -v /mnt/bt:/mnt/bt/kodi \
       --env USERNAME=myname \
       --env PASSWORD=mypassword \
       haven200/transmission-daemon

• USERNAME 变量为登录的用户名
• PASSWORD 变量为登录的密码

---
